AT91SAM7X256-CU

AT91SAM7X256-CU

Microchip Atmel ARM 7 SAM7X Microcontroller 32-bit 55MHz 256KB 100TFB

The Microchip's ARM-based SAM7X256 is a member of the Microchip SAM7X series of microcontrollers based on the 32-bit ARM7TDMI processor. It operates at a maximum speed of 55 MHz and features 256KB of flash memory and 64KB of SRAM. The peripheral set includes USB 2.0 Full Speed device port , Ethernet MAC 10/100 port, CAN 2.0A and 2.0B compliant Controller, two USART, UART, two SPI, SSC, TWI (I2C), three 16-bit timers, RTT and 8x10-bit ADC. Typical core supply is 1.8V, I/Os are supplied at 1.8V or 3.3V and are 5V tolerant. An integrated voltage regulator allows single supply at 3.3V. The SAM7X256 is supplied in 100-lead LQFP and TFBGA packages.

• Part Family ARM7TDMI
• Max CPU Speed MHz 55
• Program Memory Size (KB) 256
• SRAM (KB) 64
• Temperature Range (C) -40 to 85
• Operating Voltage Range (V) 3 to 3.6
• Direct Memory Access Channels 13
• SPI 2
• I2C 1
• Peripheral Pin Select / Pin Muxing Yes
• Ethernet 10/100 Base-TX Mac
• Number of USB Modules 1
• USB Interface FS Device
• Number of CAN modules 1
• ADC Input 8
• Max ADC Resolution (Bits) 10
• Max ADC Sampling Rate (ksps) 384
• Input Capture 3
• Max 16-bit Digital Timers 3
• Internal Oscillator 32Khz
• Max I/O Pins 62
• Pincount 100
